COPYRIGHT C 1999 CANON INC. CANON 2220/2210/2200/160/3000 REV.1 FEB. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
A-2
FIGURE A
ASSEMBLY LOCATION DIAGRAM (2/2)
810 810A
FIXING ASSEMBLY
972
SENSOR PCB ASSEMBLY
260
MAIN DRIVE ASSEMBLY
261
MULTI DRIVE ASSEMBLY
310
PAPER PICK-UP ASSEMBLY
320
MANUAL FEED TRAY ASSEMBLY
325
REGISTRATION ROLLER ASSEMBLY
930
DC CONTROLLER ASSEMBLY
330
PAPER FEED BELT ASSEMBLY
160
COPYBOARD COVER ASSEMBLY
