FIGURE
&
KEY NO.
PART NUMBER DESCRIPTION SERIAL NUMBER / REMARKS
R
A
N
K
Q
/
T
Y
COPYRIGHT C 1999 CANON INC. CANON 2220/2210/2200/160/3000 REV.1 FEB. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
102 - 30 FB4-5551-000 1 BLOCK, SPRING
31 FF5-7257-000 1 PIN, POSITIONING, LEFT
32 FS6-2910-000 1 SPRING, COMPRESSION
33 FA9-2753-000 1 SCREW,M4X10
34 FB4-5514-000 1 BLOCK, POSITIONING
35 FB4-5565-000 1 LABEL, RAIL
36 XA9-0629-000 5 SCREW,RS,M4X8
37 XD1-3100-409 1 WASHER,SPRING
38 FB4-5551-000 1 BLOCK, SPRING
39 FB4-5564-000 1 SCREW, ADJUSTING
40 FF5-7257-000 1 PIN, POSITIONING, LEFT
41 FS6-2910-000 1 SPRING, COMPRESSION
42 FB4-5532-000 1 CASSETTE DAMPER UNIT
43 FB4-5533-000 1 PLATE, DAMPER
44 FB4-5534-000 1 MOUNT, DAMPER
45 XA9-0629-000 2 SCREW,RS,M4X8
46 FB4-5527-000 2 PLATE, COVER
47 FB4-5529-000 1 HANDLE
48 FB4-5530-000 1 LEVER, RELEASE
49 FB4-5531-000 1 SHAFT
50 FB4-5560-000 1 PLATE, RAIL
51 WC4-0138-000 1 MICROSWITCH SW301 J364,365
52 WT2-5026-000 3 CLIP, CABLE
53 XA9-0605-000 2 SCREW,P,M4X8
54 XA9-0629-000 4 SCREW,RS,M4X8
55 FB4-5561-000 1 GUIDE, CABLE
56 VS1-6173-012 1 CONNECTOR, 12P J379
57 FG2-9760-000 1 DRIVE CABLE J151,152,156,351,352
J367,368,371,372
J375-377
57 A VS1-5057-005 1 CONNECTOR, SNAP TIGHT J367
102-3
