FIGURE
&
KEY NO.
PART NUMBER DESCRIPTION SERIAL NUMBER / REMARKS
R
A
N
K
Q
/
T
Y
COPYRIGHT
C
1999 CANON INC. CANON 2220/2210/2200/160/3000 REV.1 FEB. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
102 - 58 FB4-5503-000 2 MOUNT, ADF
59 FB4-5525-000 1 COVER, CABLE
60 FB4-5541-000 1 BLOCK, CARTRIDGE RELEASE
61 XA9-0629-000 7 SCREW,RS,M4X8
62 FS6-2912-000 1 SPRING, TENSION
63 WT2-0317-000 3 CLIP, CABLE
64 FA3-8727-000 1 RING, RETAINING
65 WT2-5547-000 4 CLIP, CABLE
66 FB4-5848-000 1 PLATE, GUIDE
67 FH2-6543-000 2 CORD, GROUNDING
501 XB7-2100-509 1 NUT,HEX,M5
502 XB1-2231-009 1 SCREW,MACH.,TRUSS HEAD,M2.3X10
503 XB6-7300-607 2 SCREW,TP,M3X6
102-4
