FIGURE
&
KEY NO.
PART NUMBER DESCRIPTION SERIAL NUMBER / REMARKS
R
A
N
K
Q
/
T
Y
COPYRIGHT C 1999 CANON INC. CANON 2220/2210/2200/160/3000 REV.1 FEB. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
330 - FG6-1216-030 1 PAPER FEED BELT ASSEMBLY 100V
FG6-1257-000 1 PAPER FEED BELT ASSEMBLY 120/230V
1 FB4-5618-000 1 PLATE, TERMINAL
2 FB4-5619-000 1 PLATE, TERMINAL
3 FB4-5620-000 1 PLATE, TERMINAL
4 FB4-5621-000 1 PLATE, TERMINAL
5 FB4-5622-000 2 PIN 100V
FB4-5622-000 3 PIN 120/230V
6 FB4-5623-000 2 GUIDE, PIN 100V
FB4-5623-000 3 GUIDE, PIN 120/230V
7 FB4-5624-000 1 SPRING, COMPRESSION
8 FB4-5625-000 1 SPRING, COMPRESSION
9 FB4-5626-000 1 SHEET, INSULATING 100V
FB4-5644-000 1 SHEET, INSULATING 120/230V
10 FB4-5628-000 1 GUIDE, PAPER FEED 100V
RB2-1895-000 1 GUIDE, PAPER FEED 120/230V
11 RB1-6192-000 1 SHAFT
12 FB4-5649-000 2 PULLEY 100V
RB1-6195-000 2 PULLEY 120/230V
13 RB1-6196-000 1 PLATE, GROUNDING, 1
14 RB1-6200-000 3 PIN
15 RB2-1880-000 1 GUIDE, PAPER FEED
16 RB2-1881-000 1 ELIMINATOR, STATIC CHARGE
17 RB2-1886-000 1 SHAFT, DRIVE
18 RB2-1887-000 1 BELT, PAPER FEED, 1
19 RB2-1888-000 2 BELT, PAPER FEED, 2
20 RB2-1901-000 1 PLATE, GROUNDING, 2
21 RB2-1904-000 1 BUSHING
22 RH9-0737-000 1 VARISTOR TH1301
23 RS5-2431-000 1 SPRING, COMPRESSION
330-2
