FIGURE
&
KEY NO.
PART NUMBER DESCRIPTION SERIAL NUMBER / REMARKS
R
A
N
K
Q
/
T
Y
COPYRIGHT
C
1999 CANON INC. CANON 2220/2210/2200/160/3000 REV.1 FEB. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
330 - 24 RS5-2933-000 2 SPRING, COMPRESSION
25 RS5-2934-000 1 SPRING, COMPRESSION
26 RS5-2937-000 1 PLATE, GROUNDING
27 RS6-0351-000 1 GEAR, 26T
28 RS6-0352-000 1 GEAR, 36T
29 RG5-3527-000 1 TRANSFER ROLLER ASSEMBLY
30 RB2-1903-000 1 BUSHING
31 RB2-1905-000 1 COVER
32 RB2-1899-000 1 SPRING, LEAF 120/230V
33 RB2-1908-000 1 SHEET, CORONA 120/230V
34 RB2-1896-000 1 ELIMINATOR, STATIC CHARGE 120/230V
35 FB4-5643-000 1 SPRING COMPRESSION 120/230V
501 XB4-7401-207 2 SCREW,TAPPING,TRUSS HEAD,M4X12 120/230V
330-3
