CHAPTER 1 GENERAL DESCRIPITON
VII. IMAGE FORMATION
A. Outline
The machine uses an indirect photostatic reproduction method, and is constructed as shown in
Figure 1-701.
Figure 1-701
Image processing block
Laser scanner
unit
Fixing cleaning
assembly
Lens/CCD
Fixing assembly
Pick-up from the
multifeeder
Developing
assembly
Drum
cartridge
Primary charging roller
Pre-exposure
lamp
Separation
static eliminator
Transfer
charging roller
Scanning lamp
Copyboard glass
Pick-up from the
cassette/deck
