Canon GP405 - Paper Sensor; Power Supply Pcb

COPYRIGHT © 1999 CANON INC. CANON 405/335 REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
14-67
CHAPTER 14 TROUBLESHOOTING
8 7 6 5 4 3 2 1
DC controller PCB
(DC driver)
J102-A
12
12
345
J105
J101
12345
J601
1212
J204
J203
12
J600
38VU VSS
24VU VSS
24VU VSS
Low-voltage
power supply PCB
Composite
power supply PCB
-12V 15V VSS VSS 5.1V
1234
J111
PS14S 0V SIDE_B✽ SIDE_B SIDE_A✽ SIDE_A +24V -24V
J416
J29
J424A
M
J429
J52
M9
PS 10
Horizontal registration
paper sensor
Horizontal
registration motor
DC-CON>P004-bit11
Figure 14-403 E051
