Canon GP405 - F. Saddle Finisher-C2

COPYRIGHT © 1999 CANON INC. CANON 405/335 REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
14-235
CHAPTER 14 TROUBLESHOOTING
F. Saddle Finisher-C2
Code
E584
E540
Detail code
0001
0002
0003
0001
0002
0003
Error
• Tray lifter motor (M5)
• Tray lifter motor clock
sensor 1/2 (PI19, PI9)
• Tray home position sensor
(PI8)
• Tray upper limit detecting
switch (MS4)
• Tray lifter motor (M5)
• Tray lifter motor clock
sensor 1/2 (PI19/PI20)
• Feeder motor (M1)
• Shutter closed sensor (PI5)
• Feeder motor (M1)
• Shutter closed sensor (PI5)
• Safety area detecting
switch (MS3)
• Shutter closed detecting
switch (MS4)
Description
• The upward movement does not
end within 15 sec when the tray
lifter motor has been driven.
• The tray home position is not
detected even when the tray lifter
motor has been driven for 15 sec.
• The tray upper limit detecting
switch turned on while the tray is
moving upward.
• The clock sensor 1/2 does not
generate clock pulses for 200 msec
or more even when the tray lifter
motor has been driven.
• The shutter closed detecting switch
does not turn on even when the
feeder motor has been driven in
reverse for 1 sec or more.
• The shutter open sensor does not
turn on even when the feeder motor
has been driven in reverse for 1 sec
or more.
• The shutter detecting switch turned
off when the tray 1/2 is in the
safety area switch OFF position.
Code
E5F0
Detail code
0001
0002
Error
• Paper positioning plate
motor (M4S)
• Paper positioning plate
home position sensor
(PI7S)
Description
• The paper positioning plate home
position sensor does not turn on
even when the paper positioning
plate motor has been driven for
1.25 sec or more.
• The paper positioning sensor does
not turn off even when the paper
positioning plate motor has been
driven for 1 sec or more.
