Canon GP405 - C. Cassette Feeding Unit-R1;S1

CHAPTER 14 TROUBLESHOOTING
14-232
COPYRIGHT © 1999 CANON INC. CANON 405/335 REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
C. Cassette Feeding Unit-R1/S1
Code
E901
E716
Cause
The pedestal has an error.
• The pedestal controller PBC has an
error.
• The connector has poor connection.
• The 24-V power supply has a fault.
• The pedestal motor (M20) has a fault.
• The pedestal controller PCB has a
fault.
Description
The communication IC (Q101)
on the pedestal controller PCB
is out of order.
• The pedestal motor does not
rotate at a specific speed
within 10 sec after it has
turned on.
• The pedestal motor speed
deviates
D. Multi Output Tray-D1
Code
E540
Cause
The shift tray home position sensor fails.
Description
The home position detection
signal does not turn on within 5
sec when making a shift tray
home position search.
