Canon imagePROGRAF iPF510 User Manual

v��� Contents
Contents
Add�t�onal Sett�ngs Pane (Mac OS 9) ......................................................................................527
Color Sett�ngs Pane: Color (Mac OS 9) ..................................................................................528
Color Sett�ngs Pane: Monochrome (Mac OS 9) ......................................................................531
Med�a Deta�led Sett�ngs D�alog Box (Mac OS 9) .....................................................................533
V�ew Sett�ngs D�alog Box for the Pr�nt�ng Appl�cat�on (Mac OS 9) ..........................................534
Spec�al Sett�ngs D�alog Box (Mac OS 9) .................................................................................535
Pr�ntmon�tor ..................................................................................................536
�magePROGRAF Pr�ntmon�tor (Mac�ntosh) .............................................................................536
Network Setting 537
Network Sett�ng ............................................................................................537
Network Env�ronment ..............................................................................................................537
Conguring the IP Address on the Printer ...............................................................................539
Conguring the IP Address Using imagePROGRAF Device Setup Utility ...............................540
Conguring the IP Address Using the Printer Control Panel ...................................................541
Conguring the IP Address Using ARP and PING Commands ...............................................543
Us�ng RemoteUI ......................................................................................................................544
Conguring the Printer's TCP/IP Network Settings .................................................................545
Conguring the Printer's AppleTalk Network Settings .............................................................547
Conguring the Printer's NetWare Network Settings ...............................................................548
Spec�fy�ng Pr�nter-Related Informat�on ....................................................................................550
Conguring the Communication Mode Manually .....................................................................551
Email Notication When Printing is Finished or Errors Occur .................................................553
In�t�al�z�ng the Network Sett�ngs ..............................................................................................554
Network Sett�ng (W�ndows) ..........................................................................555
Conguring the Printer Driver Destination (Windows) .............................................................555
Shar�ng the Pr�nter �n W�ndows ...............................................................................................556
Conguring the Printer's NetWare Network Settings ...............................................................558
Specifying the Printer's Frame Type ........................................................................................560
Spec�fy�ng NetWare Pr�nt Serv�ces ..........................................................................................563
Spec�fy�ng NetWare Protocols .................................................................................................566
Conguring NetWare Network Settings ...................................................................................568
Install�ng �magePROGRAF Dev�ce Setup Ut�l�ty .....................................................................569
Conguring the IP Address Using imagePROGRAF Device Setup Utility ...............................569
Network Sett�ng (Mac�ntosh) .........................................................................570
Conguring the Printer Driver Destination (Macintosh) ...........................................................570
Conguring the Printer's AppleTalk Network Settings .............................................................571
Conguring the Destination for AppleTalk Network (Macintosh) .............................................572
Conguring the Destination for TCP/IP Network (Macintosh) .................................................576
Conguring the Destination for Bonjour Network (Macintosh) ................................................580
Adjustments for Better Print Quality 581
Adjust�ng the Pr�nthead .................................................................................581
Correct�ng Pr�nt M�sal�gnment .................................................................................................581
Adjust�ng the Pr�nthead Al�gnment Automat�cally ....................................................................581
Adjust�ng the Pr�nthead Al�gnment Manually ...........................................................................583
Adjust�ng the Pr�nthead He�ght ................................................................................................586

Canon imagePROGRAF iPF510 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Yellow
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	A2 (420 x 594 mm)
Architectural sizes	8”, 10”, 14”, 16”, 17”
Maximum roll length	18 m
Paper tray media types	Banner, Cut sheet, Matte paper, Plain paper, Roll
ISO A-series sizes (A0...A9)	A2, A3, A4
ISO B-series sizes (B0...B9)	B3, B4
JIS B-series sizes (B0...B9)	B4
Photo paper sizes (imperial)	8x10, 10x12, 10x15, 12x16, 14x17, 16x20 \
Borderless printing media sizes	Legal, Letter
Compliance industry standards	IEEE 802.3, 802.3u
Power requirements	AC 100-240V (50/60 Hz)
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	100 W
Display	LCD
Certification	RoHS, IT ECO, WEEE, CE, TUV, GS, Gost-R, CB
Internal memory	192 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
Wi-Fi	-
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10Base-T, 100base-TX Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IPX/SPX, SNMP HTTP, TCP/IP, AppleTalk
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Package weight	57000 g

Weight and Dimensions

Size (imperial)	17 \
Dimensions (WxDxH)	819 x 733 x 317 mm
