Canon imagePROGRAF iPF510 User Manual

Problems Regarding Paper
Roll paper cannot be inserted into the Paper Feed Slot
Cause Corrective Action
The roll paper is warped. Straighten out curls and reload the roll.
The roll was pulled out by force when it had been
advanced before printing, and this action closed the
Paper Feed Slot .
Hold down the Stop/Eject button for a while and
reload the roll.
Cannot load sheets in the tray
Cause Corrective Action
The paper source selection is incorrect. Press the Feeder Selection button to activate the
Paper T ray lamp .
Paper is not cut straight
Cause Corrective Action
The paper is bent or curled at the cut position. Straighten out any curling by the edges of the paper .
Paper rises by the ends of the cut position before
it is cut.
Reload the paper correctly .
Paper cannot be cut
Cause Corrective Action
The printed document became caught on a foreign
object by the Output T ray , which lifted the document.
The Cutter passed under the paper .
Remove the foreign object by the Output T ray to
enable the printer to eject the printed document,
keeping it level.
In the printer driver , No or Print Cut Guideline is
specied in Auto Cut .
Specify Y es in Auto Cut in the printer driver .
In MAIN MENU , Eject or Manual is specied in
Cutting Mode .
Specify Automatic in Cutting Mode in MAIN MENU .
Depression on the leading edge is left
Cause Corrective Action
Keeping a roll in the printer for a long time without
printing on it may leave a depression on the leading
edge.
When printing quality is most important, we
recommend setting T rimEdge Reload to On or
Automatic so that the paper edge is automatically
cut before printing.
Roller marks are left across the trailing edge of paper
Cause Corrective Action
Following the instructions, press the ▲ button,
remove the paper , and then press the ▼ button.
A document was removed after printing from the
Front Paper Feed Slot without pressing the ▲ button.
Wipe away any soiling on the rollers.
( → P .627)
( → P .630)
652 T roubleshooting

Canon imagePROGRAF iPF510 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Yellow
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	A2 (420 x 594 mm)
Architectural sizes	8”, 10”, 14”, 16”, 17”
Maximum roll length	18 m
Paper tray media types	Banner, Cut sheet, Matte paper, Plain paper, Roll
ISO A-series sizes (A0...A9)	A2, A3, A4
ISO B-series sizes (B0...B9)	B3, B4
JIS B-series sizes (B0...B9)	B4
Photo paper sizes (imperial)	8x10, 10x12, 10x15, 12x16, 14x17, 16x20 \
Borderless printing media sizes	Legal, Letter
Compliance industry standards	IEEE 802.3, 802.3u
Power requirements	AC 100-240V (50/60 Hz)
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	100 W
Display	LCD
Certification	RoHS, IT ECO, WEEE, CE, TUV, GS, Gost-R, CB
Internal memory	192 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
Wi-Fi	-
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10Base-T, 100base-TX Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IPX/SPX, SNMP HTTP, TCP/IP, AppleTalk
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Package weight	57000 g

Weight and Dimensions

Size (imperial)	17 \
Dimensions (WxDxH)	819 x 733 x 317 mm
