Adjusting the Printhead
Adjustments for Better Print Quality
Adjusting the Printhead
Correcting Print Misalignment
If printed vertical lines are warped or colors are out of alignment, adjust the Printhead alignment. Adjust the
Printhead alignment automatically or manually by using a printed test pattern.
For instructions on automatic adjustment, see “Adjusting the Printhead Alignment Automatically”. (→P .581)
For instructions on manual adjustment, see “Adjusting the Printhead Alignment Manually”. (→P .583)
Adjusting the Printhead Alignment Automatically
If printed vertical lines are warped or colors are out of alignment, adjust the Printhead alignment. Adjust the
Printhead alignment automatically or manually by printing and reading a test pattern.
There are two modes for automatic adjustment: Standard Adj. and Advanced Adj. . Standard Adj. will x
most slight image distortion or color misalignment, but if not, try Advanced Adj. .
If using special media or printing does not improve even after performing automatic adjustment using
advanced adjustment, try manual adjustment. For instructions on manual adjustment, see “Adjusting the
Printhead Alignment Manually”. (→P .583)
Follow these steps for standard automatic adjustment of the Printhead .
1. Prepare one unused sheet A4/Letter-sized or larger when Standard Adj. is selected or ve
when Advanced Adj. is selected.
When using a roll, load a roll 10 inches (254 mm) or wider .
• Loading Sheets in the Cassette (→P .152)
• Loading Sheets Manually (→P .155)
• Loading Rolls on the Roll Holder (→P .1 14)
• Loading Rolls in the Roll Feed Unit (→P .1 16)
• Loading the Roll in the Printer (→P .1 17)
Adjustments for Better Print Quality 581
