Control Panel
Adjust Printer
Setting Item Description, Instructions
Standard Adj. Choose Y es to have the printer print and read a test pattern
for automatic adjustment of the Printhead alignment relative to
the printing direction. ( → P .581)
Advanced Adj. Choose Y es to have the printer print and read a test pattern for
the automatic adjustment of Printhead alignment relative to the
nozzle, ink tank, and printing direction.
Six sheets are required when printing on sheets.
( → P .581)
Auto Head Adj.
Auto Print Choose On to have the printer automatically execute the
Advanced Adj. operations after you replace the Printhead .
( → P .581)
Manual Head Adj Choose Y es to print a test pattern for adjustment of Printhead
alignment relative to the printing direction. Enter the adjustment
value manually based on the resulting pattern. ( → P .583)
Standard Adj. Choose Y es to have the printer print and read a test pattern
for band adjustment, based on which the printer automatically
adjusts the feed amount. ( → P .587)
Auto Band Adj.
Advanced Adj. Choose this option when using paper other than genuine Canon
paper , or paper for purposes other than checking output.
Choose Y es to have the printer print and read a test pattern
for band adjustment, based on which the printer automatically
adjusts the feed amount. Note that this function takes more
time and requires more ink than Standard Adj. .
T wo sheets are required when printing on sheets.
( → P .587)
Manual Band Adj Choose Y es to print a test pattern for adjusting the feed amount
based on the paper type.
T wo sheets are required when printing on sheets.
( → P .590)
Adj Far Ed Feed Choose Y es to print a test pattern for adjusting the feed amount
of the trailing edge of paper based on the paper type.
( → P .590)
Adjust Length Choose Y es to print a test pattern for adjustment relative to
paper stretching or shrinkage, after which you can enter the
amount of adjustment. ( → P .594)
56 Printer Parts
