Control Panel
Submenu Display
Press the Information button to display the following information, one item after another: remaining ink levels
and Maintenance Cartridge capacity , size and type of the paper loaded in the Cassette , size and type of the
paper loaded in the tray , roll width and remaining length, and roll type.
Remaining ink levels and Maintenance Cartridge capacity
The remaining level of each ink is shown on the Display Screen bottom line at left. These levels shown on the
Display Screen correspond to the inks identied by the Color Label below the Display Screen .
Remaining ink is indicated in seven levels.
Note
• When Ink T ank are not installed, the level is not displayed.
• If error messages about Ink T ank are displayed, the level is indicated with one dot.
• If you disable ink level detection, a question mark “?” is displayed.
• When no more ink is left, the level indicator changes to a blank square and ashes.
The remaining capacity of the Maintenance Cartridge is shown on the Display Screen bottom line at right.
The available capacity of the Maintenance Cartridge is indicated in seven levels.
Cassette type
Displays the type of paper loaded in the Cassette .
Cas Paper T ype
Plain Paper
Cassette paper size
Displays the size of paper loaded in the Cassette .
Cas Paper Size
ISO A4
62 Printer Parts
