Adjusting the feed amount
3. Press ◄ or ► to select Adjust Printer , and then press ▼ .
MAIN MENU
Adjust Printer ↓
4. Press ◄ or ► to select Adjust Length , and then press ▼ .
Adjust Printer
Adjust Length ↓
5. Press ◄ or ► to select Y es , and then press the OK button.
The setting is updated, and an equals sign “=” is displayed at left.
Adjust Length
= Y es
A test pattern is printed for adjustment based on the amount of paper stretching or shrinkage.
The scale bar shows “Millimeter” in 50 mm units and “Inch” in 1 inch units.
Note
• The following screen is displayed if automatic feeding is selected when an optional Roll Feed Unit
is installed but no roll is loaded. In this case, select the paper source and press the OK button. If
Cassette is selected on the following screen, or if automatic feeding is selected when an optional
Roll Feed Unit is not installed, select the type and size of paper loaded in the Cassette .
Media Source
= Roll
6. Measure the length of the adjustment pattern. Calculate the dif ference between the measured
length and actual length. Enter it as a percentage and press the OK button.
Y ou can adjust the value in 0.02 0ncrements. Press ◄ to increase the value and ► to decrease it.
Adjust Length
=0.02%
If the scale is printed shorter than actual size, set the value toward the positive side; if it is printed
longer , set the value toward the negative side.
The setting for the amount of paper stretching or shrinkage is relative. If you access it again
later , it will be displayed as 0.00%.
Note
• Y ou can also specify the adjustment value by selecting Adjust Length in Med.Detail Set. .
Adjustments for Better Print Quality 595
To Next Page
