1- 14
 What’s On the Operation Panel?
TOP
Chapter 3
Printing by Objective
Chapter 4
Maintenance
Chapter 5
Using the Printer
in a Network
Environment
Chapter 6
Troubleshooting
Chapter 7
Operating the
Function Menu
Index
Contents
Chapter 2
Using Various Media
Chapter 1
Basic Use
Reading Operation Panel Lamps
The lamps on the operation panel indicate the following
states.
a Data lamp
z Flashing:
If the printer is printing, this indicates that the printer is
receiving or processing a print job.
If the printer is not printing, the printer is either in pause
mode and has a paused job, or the printer has received
data that it cannot process, or the firmware is being
updated.
z Off:
There are no jobs in the printer.
b Message lamp
z On:
A warning is displayed on the operation panel.
z Flashing:
An error has occurred.
z Off:
The printer is operating normally, or the printer is
switched off.
c Roll Media lamp
z On:
Roll media is selected as the paper source.
d Cut Sheet lamp
z On:
Cut sheet is selected as the paper source.
e Online lamp
z On:
The printer is online or the printer is processing or
spooling a print job.
z Off:
The printer is either offline, in pause mode, in menu
mode, is initializing immediately after power on, or has
been switched off.
Data
Information Power
Offline
Menu
Message
e
a
b
c
d
Online
Cleaning
(3 sec.)
Stop/Eject
(1 sec.)
