Aligning the Printhead
If printed vertical lines are bent, or if colors are faded and
uneven, adjust the printhead position. The printer will print the
printhead adjustment pattern and read the pattern as it prints it
to adjust the position of the printhead automatically. Before you
adjust the position of the printhead, make sure roll media or cut
sheets of A3 size or wider are loaded in the printer.
Follow this procedure to adjust the printhead.
Note
z
When you adjust the printhead, you should use the type
of media (other than film) that you use most frequently.
z If you are using cut sheets, make sure you load at
least one sheet of unused A3 paper (not the blank side
of used paper).
Aligning Printhead Procedure
1 If the printer power is off, press the Power
button to turn the printer on.
Within a short time, Online or Offline is displayed.
2 Press the Online button to display MAIN
MENU.
3 Press [] or [] to select Adjust Printer
then press [
].
4 Press [] or [] to select Auto Head Adj.,
then press [
].
MAIN MENU
Adjust Printer ↓
Adjust Printer
Auto Head Adj. ↓
Data
Information Power
Offline
Menu
Message
Online
Cleaning
(3 sec.)
Stop/Eject
(1 sec.)
MAIN MENU
Head Cleaning
Online
Cleaning
(3 sec.)
Stop/Eject
(1 sec.)
To Next Page
