Specifications
W8400
Print Features
Print Method Serial Bubble Jet
Print Modes Highest (Custom Settings), High, Standard, Draft
Max. Resolution 2400 x 1200 dpi
Interface
USB Interface
(USB 2.0 Standard)
1
(If the computer port, operating system, or USB cable does not support USB 2.0 High Speed
Mode, you will not be able to use High Speed Mode.)
*1
Network Interface
(10base-T/100base-TX)
Option
*2
IEEE1394 Interface
(IEEE1394.a standard)
Option
*2
Interface Connector
USB Interface: USB Standard Series B Receptacle
USB Interface Recommended Printer Cable:
Material: AWG28 or above
Type: Twisted-pair sealed cable (high speed mode compliant)
Length: 5.0 m max.
Connector: USB Standard Series B Plug
IEEE1394 Interface (option): IEEE1394-1995 Standard 6-pin (without feed)
IEEE1394 Interface Recommended Printer Cable:
Material: AWG28 (signal) AWG22 (power) or later
Type: Dual twisted pair shielded cable (100, 200, 400 Mbps mode compliant)
Length: 4.5 m max.
Connector: IEEE1394-1995 Compliant 6-pin
Printhead Replacement Printhead BC-1350
Resolution 1200 dpi (600 dpi x 2 lines)
Number of nozzles 1280 nozzles per color x 6 colors
