Replacing the Cutter Blade
Follow the procedure below to replace the cutter blade
when it no longer cuts cleanly.
z Replacing Standard Cutter Blades (Flat Cutters)
(
→ P.4-27)
z Replacing Optional Cutter Blades (Round
Cutters) (
→ P.4-30)
Replacing Standard Cutter Blades
(Flat Cutters)
Change the cutting position of a blade when the blade no
longer cuts cleanly. The cutting position can be changed
twice for each blade. Once the cutting position adjustment
dial is set to 3, replace the blade with a new one.
z Cutter Blade CT-02
1 If the printer power is off, press the Power
button to switch the printer on.
After a few moments, Online appears in the display.
2 Press the Online button to display MAIN
MENU.
3 Press [] or [] to display System Setup
then press [
].
4 Press [] or [] to select Change Cutter,
then press [
].
MAIN MENU
System Setup ↓
System Setup
Change Cutter ↓
Data
Information Power
Offline
Menu
Message
Online
Cleaning
(3 sec.)
Stop/Eject
(1 sec.)
MAIN MENU
Head Cleaning
Online
Cleaning
(3 sec.)
Stop/Eject
(1 sec.)
To Next Page
