a Bk Ink Tank or MBk Ink Tank
b PC Ink Tank
c C Ink Tank
d PM Ink Tank
e M Ink Tank
f Y Ink Tank
These are the ink cartridges. The printer is shipped
without the ink cartridges installed. You must install the
ink cartridges after unpacking the printer.
g Bk/MBk Ink Tank Covers
h PC Ink Tank Cover
i C Ink Tank Cover
j PM Ink Tank Cover
k M Ink Tank Cover
l Y Ink Tank Cover
These covers lock and protect the ink tanks. Open this
cover to replace an ink tank.
g
h
i
j
k
l
a
b
c
d
e
f
