30 Chapter 5 Acquiring Panoramic Images
Note: To acquire a bitewing segmented panoramic image:
• Click .
• Select one or both area of interest.
• Position the patient in the Camper
plane alignment (horizontal occlusion) as
shown.
For a more accurate Camper plane alignment,
you can:
• Use the panoramic chin rest (A).
• Fit the standard bite block or edentulous
bite stick to the panoramic chin rest (B).
A B
Important: Do not use the Frankfort guide bite block when
performing bitewing procedures.
Important: The acquisitions that you obtain using the bitewing
segmented panoramic program are not equivalent to an intraoral
bitewing examination.
