Panoramic and 3D Modality User guide for CS 8100 3D Family (SM842) Ed07 51
Store the standard temple support carefully, and replace it when you have completed the focused
offset acquisition.
4. Ask the patient to enter the unit. On the Positioning panel, press and hold to raise the chin
rest to the height of the patient.
5. Ask the patient to:
6. To position the patient:
• Stand up straight (do not position the
feet slightly forward).
• Grip both the lower handles of the
head and chin rest.
• Relax and lower the shoulders for full
motion of the unit rotative arm.
Important: Remember to store the standard temple support
carefully, and to replace it once you have completed the offset
acquisition.
Note: If the patient is too tall, ask the patient to sit on a stool.
