20060301
1-9-9
Configuring Application Format Settings
• The above is the same as the [G-Controller] setting on the Graph Format dialog box.
u
G-Controller
To do this: Do this:
Turn on display of graph controller arrows
during graphing
Select the [G-Controller] check box.
Turn off display of graph controller arrows
during graphing
Clear the [G-Controller] check box.*
k
Geometry Format Dialog Box
Use the Geometry Format dialog box to configure settings for the Geometry application.
Tip
• The information that appears in the preview area at
the bottom of the dialog box shows a preview of the
Geometry application window, based on the settings
configured in upper half of the dialog box.
u
Number Format
To specify this type of numeric value display format on
the Geometry window:
Select this setting:
Auto exponential display for values less than 10
–2
and from
10
10
or greater (when you are in the Decimal mode)
Normal 1
Auto exponential display for values less than 10
–9
and from
10
10
or greater (when you are in the Decimal mode)
Normal 2
Fixed number of decimal places Fix 0 – 9
Fixed number of significant digits Sci 0 – 9
• The initial default [Number Format] setting is Fix 2.
