20060301
Tip
• The two sides of a figure actually forms four angles, numbered
1
through
4
in the illustration
shown here. After attaching an angle measurement using the [Attached Angle] command, you
can drag it to the position of any one of the other three angles as shown in the examples below.
4
1
2
3
u
To attach an angle measurement to a figure
Example: To attach the measurement of angle A in the triangle ABC
(1) Draw the triangle.
(2) Tap
G
. Next, tap side AB and then side AC to select them.
(3) Tap [Draw] and then [Attached Angle].
• This attaches the angle measurement to the figure.
8-2-20
Drawing Figures
