CG emotron TSA Series User Manual

CG Drives & Automation, 01-5980-01r2 Functionality 87
Modbus RTU [262]
Set up the parameters for Modbus/RTU) communication.
Baudrate [2621]
Set the baud rate for the communication.
Address [2622]
Enter the unit address for the softstarter.
Fieldbus [263]
Set up the parameters for fieldbus communication.
Address [2631]
Enter or view the unit/node address of the softstarter. Read
& Write access for Profibus and DeviceNet. Read-only for
EtherCAT*.
*) EtherCAT is a future option.
Process Data Mode [2632]
Enter the mode of process data (cyclic data). For further
information, see the Fieldbus option manual.
Read/Write [2633]
Select “Read/Write” to control the softstarter over a fieldbus
network. For further information, see the Fieldbus option
manual.
Additional Process Values [2634]
Define the number of additional process values sent in cyclic
messages.
NOTE: This baud rate is valid only for communication via
the RS485 and USB options.
Default: 9600
2400 0
Selected baudrate
4800 1
9600 2
19200 3
38400 4
57600 5
115200 6
NOTE: This address is valid only for communication via
the RS485 and USB options.
Default: 1
Selection: 1–247
262 Modbus RTU
Stp
2621 Baudrate
Stp 9600
2622 Address
Stp 1
263 Fieldbus
Stp
Default: 62
Range: Profibus 0–126, DeviceNet 0–63
Node address valid for Profibus(RW), DeviceNet (RW) and
EtherCAT* (RO).
Default: Basic
None 0 Control/status information is not used.
Basic 4
4 byte process data control/status
information is used.
Default: RW
RW 0 Read & Write
Read 1 Read-only
Valid for process data. Select “Read” (read-only) for logging
process without writing process data. Select “RW” in normal
cases to control inverter.
Default: 0
Range: 0-8
2631 Address
Stp 62
2632 PrData Mode
Stp Basic
2633 Read/Write
Stp RW
2634 AddPrValues
Stp 0
