CG emotron TSA Series User Manual

CG Drives & Automation, 01-5980-01r2 Functionality 129
Clock 1 Weekday [6615]
Weekdays when the clock function is active. Having entered
the editing mode, select or unselect the desired weekdays
with the cursor using the PREV and NEXT keys on the
control panel. Confirm by pressing ENTER. Exit the editing
mode and the activated weekdays will be viewed in the menu
display. The deactivated weekdays are replaced by a dash
mark “-” (e.g. “MTWTF - -”).
Example 1:
The output CLK1 shall be active Mondays to Fridays on
working hours, e.g. 08:00-17:00. This signal is used to start
e.g. a fan with virtual I/O.
Example 2:
The output CLK1 shall be active on weekends, all day.
Clock 2 [662]
Refer to the description for Clock 1 [661].
8.7 Operation/Status [700]
Menu with parameters for viewing all actual operational data,
such as speed, torque, power, etc.
8.7.1 Operation values [710]
Process Value [711]
This menu displays the actual value of the active process
signal, i.e. the same value as in menu [310].
Torque [713]-[714]
These menus displays the actual shaft torque, expressed with
different units in the two menus:
Shaft power [715]- [716]
These menus displays the actual shaft power, expressed with
different units in the two menus:
Default: 2013-01-01
Range: YYYY-MM-DD
Default: MTWTFSS (all activated)
Range:
Monday, Tuesday, Wednesday, Thursday,
Friday, Saturday, Sunday.
NOTE: Please make sure that the correct time and date
settings are done for the real time clock, menu group
[740] “Clock”.
Menu Text Setting
6611 Clk1TimeOn 08:00
6612 Clk1TimeOff 17:00
6613 Clk1DateOn 2013-02-01 (date in the past)
6614 Clk1DateOff 2099-12-31 (Date in the future)
6615 Clk1Weekday MTWTF- -
561 VIO 1 Dest Run FWD
562 VIO 1 Source Clk1
Menu Text Setting
6611 Clk1TimeOn 0:00:00
6612 Clk1TimeOff 23:59:59
6613 Clk1DateOn 2013-02-01 (date in the past)
6614 Clk1DateOff 2099-12-31 (Date in the future)
6615 Clk1Weekday - - - - - SS
561 VIO 1 Dest Run FWD
562 VIO 1 Source Clk1
6614 Clk1DateOff
Stp 2013-01-01
6615 Clk1Weekday
Stp MTWTFSS
Read-only
Unit Depends on selected process unit [322].
Resolution
Speed: 1 rpm, 4 digits
Other units: 3 digits
Read-only
Unit: Nm
Resolution: 0.1 Nm
Read-only
Unit: %
Resolution: 1 %
Read-only
Unit: W
Resolution: 1W
Read-only
Unit: %
Resolution: 1%
711 Process Val
Stp
713 Torque
Stp 0.0Nm
714 Torque
Stp %
715 Shaft Power
Stp 0W
716 Shaft Power
Stp %
