2.3 Mounting schemes
Emotron TSA frame size 1 - 2
Fig. 8 Hole pattern for Emotron TSA frame size 1 and 2.
Emotron TSA frame size 3
Fig. 9 Hole pattern for Emotron TSA frame size 3.
Emotron TSA frame size 4
Fig. 10 Hole pattern for Emotron TSA frame size 4.
On our websites www.cgglobal.com and www.emotron.com
it is possible to download a full-size template for positioning
of the fixing holes.
104.5 (4.1)
11(0.43)
273(10.7)
Ø 6,5 (x 4)
11
(043)
170(6.7)
13(0.51)
303(12)
10
Ø 13
Ø 7 (x 4)
(039)
4
25
,
5
220(8.7)
17(0.67)
390(1.4)
Ø 7 (x 4)
11
Ø 13
(043)
