CG Drives & Automation, 01-5980-01r2 Functionality 135
8.8 View Trip Log [800]
Main menu with parameters for viewing all the logged trip
data. In total the softstarter saves the last 9 trips in the trip
memory. The trip memory refreshes on the FIFO principle
(First In, First Out). Every trip in the memory is logged on
actual date and the time. At every trip, the actual values of
several parameters are stored and available for
troubleshooting.
See section 7.3.1, page 55 for an explanation of the different
alarm types.
8.8.1 Trip Message Log [810]
The trip log displays the cause of the trip and what time it
occurred (based on the actual time in [740]). The display is
showing actual trip message and alternates between showing
date and time when the trip occured.
See a list of the possible trip messages in Table 36, page 132.
When a trip occurs the operation and status menus [710] and
[720]are copied to the trip message log. There are nine trip
message logs [810]–[890]. When the tenth trip occurs the
oldest trip message will be erased.
Example:
The display is showing actual trip message and alternates
between showing date and time when the trip occurred
For fieldbus integer value of trip message, see Table 36, page
132 (menu [722]).
Trip message [8111]-[8133]
The information from the status menus are copied to the trip
message log when a trip occurs.
NOTE: After the reset of a trip, the previous menu will
appear.
Unit:
Alternating
hh:mm:ss (hours: minutes: seconds)
YYYY-MM-DD (year-month-day)
8x0 Trip Message
Trp hh:mm:ss
830 Locked Rotor
Trp 09:12:14
830 Locked Rotor
Trp 2013-04-17
Table 37 Stored trip message parameters
Trip menu Copied from Description
8.7.1 Operation values [710]
8111 711 Process Value
8113 713 Torque (Nm)
8114 714 Torque (%)
8115 715 Shaft Power (W)
8116 716 Shaft Power (%)
8117 717 El Power
8118 718 RMS Current
8119 719 L Main Volt
811A 71A Heatsink Temp
811B 71B PT100B1 123
811C 71C PT100B2 123
811D 71D Current I1
811E 71E Current I2
811F 71F Current I3
811G 71G L12 Voltage
811H 71H L13 Voltage
811I 71I L23 Voltage
811J 71J Phase Seq
811K 71K Used Thermal Cap
8.7.2 Status [720]
8121 721 TSA Status
8122 723 Digital input status
8123 724 Relay status
8124 725 Analogue input status
8125 726 Analogue output status
8126 727 I/O status option board B1
8127 728 I/O status option board B2
8129 72A Analogue comparator 1 - 4
812A 72B Digital comparator 1 - 4
812B 72C Logic function status 1-4
812C 72D Timer status 1-4
812D 72E Flip-flop status 1-4
812E 72F Counter status 1-2
812F 72G Time to next start
