The following warning or trip messages are possible:
Digital Input Status [723]
This menu indicates the status of the digital inputs. See
example in Fig. 76.
1DigIn 1
2DigIn 2
3DigIn 3
4DigIn 4
The positions 1 - 4 (on the display, from left to right) indicate
the status of the associated input (DigIn 1 - DigIn 4):
1High
0Low
The example in Fig. 76 indicates that DigIn 2 and DigIn 4
are active at this moment.
Fig. 76 Digital input status example
Relay Status [724]
This menu indicates the status of the relays. See Fig. 77.
RE indicates the status of the relays on position:
1Relay1
2Relay2
3Relay3
The status of the associated output is shown.
1High
0Low
The example in Fig. 77 indicates that Relay 1 is active. Relay
2 and Relay 3 are not active.
Fig. 77 Relay status example
Analogue Input Status [725]
This menu indicates the status of the analogue input.
Fig. 78 Analogue input status example
The status of the input is shown in [%], so the example in
Fig. 78 indicates that AnIn is active and has a 65% input
value.
Table 36 Trip and warning messages
Communication
integer value
Trip / warning message
0 No Error
1 Motor I²t
2PTC
3 Locked rotor
4Ext Alarm 1
5Ext Alarm 2
6 Curr limit (current limit)
7Start limit
8 Comm error (communication error)
9 Pt100
10 (reserved for future use)
11 (reserved for future use)
12 Mon MaxAlarm (load monitor max alarm)
13
Mon MaxPreAl (load monitor max pre-
alarm)
14
Mon MinPreAl (load monitor min pre-
alarm)
15 Mon MinAlarm (load monitor min alarm)
16 Over temp (over temperature)
17 (reserved for future use)
18 (reserved for future use)
19 Phase loss (single phase loss)
20 M Phase loss (multiple phase loss)
21 Under voltag (under voltage)
22 Mot termOpen (motor terminal open)
23 Current Unbal (current unbalance)
24
CtrlSupFault (control voltage supply
fault)
25 (reserved for future use)
26 Int error1-NTC (internal error 1)
27 Phase rev (phase reversal)
28 (reserved for future use)
29 Int Error2-AD (internal error 2)
30 Over voltag (over voltage)
31 Volt Unbal (voltage unbalance)
Read-only
Read-only
Read-only
NOTE: The shown percentage is an absolute value based
on the maximum value of the in- or output; so related to
either to 10 V or 20 mA.
723 DigIn Status
Stp 0101
724 RelayStatus
Stp RE 100
725 AnalogueIn
Stp 65%
