CG Drives & Automation 01-5980-01r2 Introduction 5
1. Introduction
The Emotron TSA softstarter is intended for controlling the
start and stop of standard three phase asynchronous motors.
A built-in powerful digital signal processor (DSP) gives the
softstarter high performance and very good control of the
starting and stopping of the application.
Several options are available, listed in chapter 12. page 155,
that enable you to customize the softstarter for your specific
needs.
Users
This instruction manual is intended for:
• installation engineers
• maintenance engineers
•operators
• service engineers
Motors
The softstarter is suitable for use with standard 3-phase
asynchronous motors. Contact your supplier for details.
1.1 Delivery and unpacking
Check for any visible signs of damage. Inform your supplier
immediately of any damage found. Do not install the
softstarter if damaged.
Check that all items are present and that the type number is
correct.
1.2 Using of the instruction
manual
Check that the software version number on the first page of
this manual matches the software version in the softstarter.
See chapter 8.9.1 page 136.
With help of the index and the table of contents it is easy to
track individual functions and find out how to use and set
them.
The Quick Start Guide can be put in a cabinet so that it is
always easy to access in case of an emergency.
1.3 Warranty
The warranty applies when the equipment is installed,
operated and maintained according to instructions in this
instruction manual. Duration of warranty is as per contract.
Faults that arise due to faulty installation or operation are
not covered by the warranty.
1.4 Type code number
Fig. 1 gives an example of the type code numbering used for
the Emotron TSA softstarter. This identification will be
required for type specific information when mounting and
installing. The code number is located on the product label,
on the right side of the unit (when viewed from the front).
Fig. 1 Type code number
NOTE: Read this instruction manual carefully before
installing, connecting or working with the softstarter.
TSA 52 -016 -23 N N N — AA—
Position number:
1 2 3 4 567891011
Ta b l e 1
Position Configuration Description
1Type TSA
2 Main supply voltage
52 = Max 525 V mains
69 = Max 690 V mains
3 Current rating
016 = 16 A
-
- 1K8 = 1800 A
4 Control voltage 23=230 V
5 Option position 1
N=No option
P=PTC/PT100
I=I/O board
6 Option position 2
N=No option
P=PTC/PT100
I=I/O board
7
Communication
option
N=No option
A=Profinet IO 1-port
B=Profinet IO 2-port
D=DeviceNet
E= EtherCAT
G=EtherNet/IP 2-port
M=Modbus/TCP
P=Profibus
R=RS485
U=USB
8 Supply type
— =Standard (Grounded
net)
I=IT-net (EMC not fulfilled)
9Brand label A=Standard
10 Software A=Standard software
11 Standard
— =CE approved
U=UL/cUL approved
