CG emotron TSA Series User Manual

136 Functionality CG Drives & Automation, 01-5980-01r2
8.8.2 Trip Messages [820] - [890]
Same information as for menu [810].
8.8.3 Reset Trip Log [8A0]
This menu resets the content of the 9 trip memories.
8.9 System Data [900]
Main menu for viewing all the softstarter system data.
8.9.1 TSA Data [920]
TSA Type [921]
This menu shows the Emotron TSA type according to the
type code. The options are indicated on the product label of
the softstarter. See section 1.4, page 5.
Fig. 81 Type number example.
Example:
TSA-series suited for 525 V mains supply, and a rated output
current of 16 A.
Software [922]
This menu shows the software version number of the
softstarter. Fig. 82 gives an example.
Fig. 82 Software version example.
8.7.3 Stored Values [730]
8131 731 Run time
8132 732 Mains time
Default: No
No 0
Yes 1
NOTE: After the reset the setting goes automatically
back to “NO”. The message “OK” is displayed for 2 sec.
Table 37 Stored trip message parameters
Trip menu Copied from Description
8A0 Reset Trip L
Stp No
NOTE: If the control board is not configured, then “Set
type” is shown.
Table 38 Information for Modbus and Profibus number,
software version
Bit Example Description
7–0 30 Minor version
13–8 4 Major version
15–14 0
Release type:
0: V, release version
1: P, pre-release version
2:
β, Beta version
3: α, Alpha version
Table 39 Information for Modbus and Profibus number,
option version
Bit Example Description
7–0 07 Minor option version
15–8 03 Major option version
921 TSA
Stp TSA52-016
922 Software
Stp V1.20
