CG emotron TSA Series User Manual

CG Drives & Automation, 01-5980-01r2 Functionality 131
8.7.2 Status [720]
TSA Status [721]
This menu indicates the overall status of the softstarter.
Fig. 75 Softstarter status
Integer values and bits used:
Example: “A/- - - /Key”
This means:
A: Parameter Set A is active.
---: Operation is stopped.
Key: Run/Stop command source is both internal and
external keyboard (in this example bit 7-5
→ 1).
Integer interpretation for “A/---/Key” is “0/0/1”.
In bit format this is presented as:
Warning [722]
This menu displays the actual warning condition. If no
warning is active the message “No Error” is displayed. A
warning occurs if the softstarter is close to a trip condition
but still in operation. During a warning condition the red
trip LED will flash, as long as the warning is active.
Read-only
Display
position
Function Status value
1 Parameter Set A, B, C, D
222 Operation
- - - (stopped)
-Thy (ramp/brake with
thyristors)
-Bpy (full speed reached,
running with bypass enabled)
333
Source of Run/
Stop command
-Rem (remote)
-Key (keyboard - external or
internal or both)
-Com (communication option)
Bit Integer representation
1 - 0
Active Parameter Set, where:
0=A, 1=B, 2=C, 3=D.
4 - 2
Operation:
0=Stopped
1=Thyristor driven motor
2=Bypass driven motor
7 - 5
Source of Run/Stop command, where:
0=Rem, 1=Keyboard (internal + external), 2=Com,
3=Spare, 4=VIO, 5=Internal keyboard, 6=External
keyboard.
15 - 8 Reserved for future use.
721 TSA Status
Stp 1/222/333
Bit no.
76543210 LSB
00100000
Key (1) - - - (0) A (0)
Source of Run/Stop
command =
Int + Ext keyboard (1)
Operation =
Stopped (0)
Parameter Set=
A (0)
Read-only
722 Warning
Stp (warning message)
