CG Drives & Automation 01-5980-01r2 Technical data 157
13. Technical data
1) Normal duty: Start current = 3 x I
n_soft
, Start time = 15 s (Size 1) or 30 s (Size 2- 4), 10 starts/hour,
Heavy duty: Start current = 5 x I
n_soft
, Start time = 15 s (Size 1) or 30 s (Size 2- 4), 10 starts/hour.
2) Fuse data for Semi-conductor fuses, see Table 48.
3) H1=Height of enclosure, H2= Total height.
Table 42 Technical data for Emotron TSA52/69-016 to -030.
Emotron TSA Size 1 model:
TSA52/69-016 TSA52/69-022 TSA52/69-030
Duty
(1)
Normal Heavy Normal Heavy Normal Heavy
Rated current I
n_soft
[A] 16 10 22 12 30 18
Motor size P
n_mot
400 V [kW] - TSA52-### 7.5 4 11 5.5 15 7.5
Motor size P
n_mot
460 V [hp] - TSA52-### 10 5 15 7.5 20 10
Motor size P
n_mot
525 V [kW] - TSA52-### 11 5.5 15 7.5 18.5 11
Motor size P
n_mot
575 V [hp] - TSA69-### 15 7.5 20 10 25 15
Motor size P
n_mot
690 V [kW] - TSA69-### 11 7.5 18.5 11 22 15
Recommended load fuses [A]
(2)
25 25 35 35 40 40
Total power loss for TSA unit at rated motor
power, in bypass mode [W]
16 15 17 15 19 16
Total average power loss for TSA unit if
10 starts/hour [W]
35 34 39 37 45 43
Dimensions H1/H2 x W x D [mm (in)]
(3)
246/340 x 126 x 188 (9.7/13.4 x 5 x 7.4)
Mounting position Vertical
Weight [kg] 5.5
Busbar for cable connection [mm (in)] 15 x 2 (0.59 x 0.08), M6 connection.
Possible to use either Cu or Al cables.
Cooling system Convection
Protection class IP20
UL short circuit rating 5 kA
Table 43 Technical data for Emotron TSA52/69-036 to -056.
Emotron TSA Size 1 model:
TSA52/69-036 TSA52/69-042 TSA52/69-056
Duty
(1)
Normal Heavy Normal Heavy Normal Heavy
Rated current I
n_soft
[A] 36 21 42 25 56 33
Motor size P
n_mot
400 V [kW] - TSA52-### 18.5 7.5 22 11 30 15
Motor size P
n_mot
460 V [hp] - TSA52-### 25 15 30 20 40 25
Motor size P
n_mot
525 V [kW] - TSA52-### 22 11 30 15 37 22
Motor size P
n_mot
575 V [hp] - TSA69-### 30 20 40 25 50 30
Motor size P
n_mot
690 V [kW] - TSA69-### 30 18.5 37 22 45 30
Recommended load fuses [A]
(2)
50 50 63 63 80 80
Total power loss for TSA unit at rated
motor power, in bypass mode [W]
20 17 21 18 25 19
Total average power loss for TSA unit if
10 starts/hour [W]
49 46 51 48 61 56
Dimensions H1/H2 x W x D [mm (in)]
(3)
246/340 x 126 x 188 (9.7/13.4 x 5 x 7.4)
Mounting position Vertical
Weight [kg (lb)] 5.5 (12.1)
Busbar for cable connection [mm (in)] 15 x 2 (0.59 x 0.08), M6 connection.
Possible to use either Cu or Al cables.
Cooling system Convection
Protection class IP20
UL short circuit rating 5 kA
