160 Technical data CG Drives & Automation 01-5980-01r2
13.1 General electrical specifications
13.2 Semi-conductor fuses
Always use standard commercial fuses to protect the wiring
and prevent short circuiting. To protect the thyristors
against short-circuit currents, superfast semiconductor fuses
can be used if preferred.
Use fuses with I
2
t values lower or equal to Table 48.
Table 47 General electric specifications.
Parameter Description
General
Mains supply voltage
200-525 V, +10%/-15%
200-690 V, +10%/-15%
Mains and Control supply frequency 50/60 Hz, ±10%
Number of fully controlled phases 3
Control supply voltage 100-240 V +10%/-15%, Single phase
Power consumption for control supply
voltage
20 VA for TSA52/69-16 to 52/69-56,
25 VA for TSA52/69-70 to 52/69-100
30 VA for TSA52/69-140 to 52/69-240
40 VA for TSA52/69-300 to 52/69-450
Fuse for control supply Max 10 A
Control signal inputs
Digital input voltage 0-4 V
->0, 8 -27 V->1
Digital input impedance to GND (0 VDC)
<3.3 VDC: 4.7 kΩ
>3.3 VDC: 3.6 kΩ
Analogue input voltage/current 0-10 V, 2-10 V, 0-20 mA, 4-20 mA
Analogue input impedance to GND (0 VDC) Voltage signal 20 kΩ, Current signal 250 Ω
Control signal outputs
Output relays contact 8 A, 250 VAC or 24 VDC resistive load; 3 A, 250 VAC inductive load.
Analogue output voltage/current 0-10 V, 2-10 V, 0-20 mA, 4-20 mA
Analogue output load impedance Voltage signal min. load 700 Ω, current signal max. load 700 ΩΩ
Control signal supply
+24 VDC +24 VDC+5%. Max current 50 mA. Short circuit and overload proof.
Table 48 Semi-conductor fuses data.
TSA model:
Semi-conductor fuse
A I
2
t (fuse) at 700 V
-016 50 1 500
-022 70 2 800
-030 100 3 600
-036 125 6 900
-042 150 11 000
-056 175 14 000
-070 250 42 000
-085 300 55 000
-100 400 99 000
-140 500 160 000
-170 600 222 000
-200 700 332 000
-240 800 433 000
-300 1000 950 000
-360 1200 1 470 000
-450 1400 1 890 000
