Procedure 6-5 (continued)
Setting the 6200 date and time
Step Action
11 Click Submit.
Changes are applied and a confirmation message is displayed.
Setting the secondary time zone of a network element
12 Click System Time in the Navigation menu.
13 Click Set time zone link.
Set Time Zone page is displayed.
14 Select Enable from the Display Enable drop down menu.
15 Select the Secondary Time Zone from the drop down menu.
16 Click Submit.
The secondary time zone is set.
Setting the time server for a network element
17 Click System Time in the Navigation menu.
18 Click Set time server link.
Set Time Server page is displayed.
19 Enable the field NTP Client Enable.
20 Enter the IP address of the server from which the network element has to
derive the date and time.
Note 1: Nominate timing server of stratum level of 14 or less than 14. The
network element will not synchronize to the server if the stratum level is not
within the range.
Note 2: If OMEA is used to manage the 6200 network element, the first NTP
servers (NTP Server-0) will automatically be provisioned. Provision all other
time servers against remaining NTP servers.
Note 3: It may take the “current NTP server” parameter up to 5 minutes to
update.
21 Select the Synchronization interval from pull-down menu.
22 Click Submit.
Changes are applied and a confirmation message is displayed.
—end—
Note 1: After setting the date and time, measure the output power and
receiver sensitivity for optical ports and record the result in Table 12-9 on
page 12-9.
Note 2: Nominate the synchronization source on 6200 network element
and record the result in Table 12-10 on page 12-10. For nominating timing
reference, refer to Provisioning and Protection Switching Procedures,
009-6200-310.
