Ciena 6200 - Connecting Ethernet Cables to 4 Xfe Interfaces of 4 Xge + 4 Xfe Circuit Pack

Installing the 6200 network element 5-53
6200 Packet-Optical Platform Installation, Commissioning, and Testing Procedures
Release 1.1 009-6200-201 Draft Issue 1
Copyright
©
2014 Ciena
®
Corporation September 2014
Procedure 5-19
Connecting Ethernet cables to 4xFE interfaces of
4xGE + 4xFE circuit pack
Use this procedure to connect the Ethernet cables to the 4xFE interfaces of
the 6200 network element.
The FE interfaces supports both Ethernet and Fast Ethernet signals.
Prerequisites
Make sure that the following tools and materials are available:
• four RJ-45 Ethernet cables
• cable ties
Action
Step Action
1 Identify the Ethernet cables.
2 Connect the appropriate Ethernet cables to the RJ-45 FE electrical interfaces
on the 4xGE + 4xFE circuit pack. For details, refer to Figure 5-30 on page
5-54.
—end—
