Ciena 6200 - Inserting Circuit Packs

Common procedures 10-9
6200 Packet-Optical Platform Installation, Commissioning, and Testing Procedures
Release 1.1 009-6200-201 Draft Issue 1
Copyright
©
2014 Ciena
®
Corporation September 2014
Procedure 10-4
Inserting circuit packs
Use this procedure for inserting the circuit pack in an 6200 network element.
The circuit pack is provided with latches that aid in the insertion and ejection
from the chassis.
You can use this procedure for inserting following circuit packs:
• 63xE1DS1 circuit pack
• 6xE3DS3 circuit pack
• 63xE1DS1WP circuit pack
• 12xE3DS3WP circuit pack
• IO63xE1DS1 circuit pack
• IO12xE3DS3 circuit pack
• 2.5G MRO circuit pack
• 15G MRO XC circuit pack
• 60G MRO XC circuit pack
• 6G PKT SW circuit pack
• 64G PKT SW circuit pack
• 4xGE + 4xFE circuit pack
Prerequisites
• Make sure that a manual Phillips screwdriver is available.
CAUTION
Risk of equipment damage
Electrostatic discharge can damage electrostatic sensitive
devices. Use antistatic protection to avoid damaging circuit
packs.
CAUTION
Risk of circuit pack damage
Do not force any circuit pack all the way back of its slot if it
resists insertion. Before you install any of the circuit packs,
make sure you understand the detailed procedure for insertion
of circuit packs.
