10-2 Common procedures
6200 Packet-Optical Platform Installation, Commissioning, and Testing Procedures
Release 1.1 009-6200-201 Draft Issue 1
Copyright
©
2014 Ciena
®
Corporation September 2014
Procedure 10-1
Inserting the power supply unit-DC PSU/Fan+OAM/
Fan+OAMV2 module
Use this procedure to insert a power supply unit-DC PSU/Fan+OAM/
Fan+OAMV2 module in an 6200.
Prerequisites
• Make sure that a manual Phillips flat and star screwdriver is available.
Action
Step Action
1 Determine your next step.
CAUTION
Risk of equipment damage
Electrostatic discharge can damage electrostatic sensitive
devices. Use antistatic protection to avoid damaging circuit
packs.
CAUTION
Risk of circuit pack damage
Do not force any circuit pack all the way back of its slot if it
resists insertion. Before you install any of the circuit packs,
make sure you understand the detailed procedure for insertion
of circuit packs.
If you want to insert a Then go to
power supply unit-DC PSU step 2 on page 10-3
Fan+OAM or Fan+OAMV2 module step 4 on page 10-3
To Next Page
