11-2 Cable color coding
6200 Packet-Optical Platform Installation, Commissioning, and Testing Procedures
Release 1.1 009-6200-201 Draft Issue 1
Copyright
©
2014 Ciena
®
Corporation September 2014
Table 11-2
Power cable
Pin North America European Union
+Ve Black Blue
GND Green-Yellow Green-Yellow
-Ve Red Gray
WARNING
To ensure that the correct polarity is connected to the DC
power supply unit, confirm the connection of the power cables
to the + (positive) and - (negative) leads at the power source.
Table 11-3
Alarm out cable
Pin Color code Signal Pair Usage
description
RJ-45
1 Blue ALARMOUT_1 P1 Critical
2 White ALARMOUT_1_COM
3 Orange ALARMOUT_2 P2 Major
4 White ALARMOUT_2_COM
5 Green ALARMOUT_3 P3 Minor
6 White ALARMOUT_3_COM
7 Brown ALARMOUT_4 P4 Unused
8 White ALARMOUT_4_COM
