11-1
6200 Packet-Optical Platform Installation, Commissioning, and Testing Procedures
Release 1.1 009-6200-201 Draft Issue 1
Copyright
©
2014 Ciena
®
Corporation September 2014
Cable color coding 11-
This chapter provides color coding details of various cables, used for installing
of the 6200 network element.
Chapter table list
Table 11-1 lists the cables and the respective tables providing color coding
details.
Refer to the Planning Guide S78-1002-110, for PEC codes and connector
pinouts.
Table 11-1
Cable color coding details
Cable Details
Power cable Table 11-2
Alarm out cable Table 11-3
Alarm in cable Table 11-4
ESI-Data cable Table 11-5
ESI-Clk Cable Table 11-6
ESI-Clk Cable (USB to RJ45 Coupler) Table 11-7
LAN/Craft cable Table 11-8
E1/DS1 LFH Cable Table 11-9
ESI DATA/CLK cable Table 11-10
