11-6 Cable color coding
6200 Packet-Optical Platform Installation, Commissioning, and Testing Procedures
Release 1.1 009-6200-201 Draft Issue 1
Copyright
©
2014 Ciena
®
Corporation September 2014
Table 11-9
E1/DS1 LFH Cable
Group Cable Pins on the
Connector
Signal
Pair Color Bundle Color
Tx GROUP
RED
BLUE
125 TIP-Tx1
GREEN 116 RING-Tx1
RED 126 TIP-Tx2
ORANGE 115 RING-Tx2
RED 127 TIP-Tx3
BLUE 114 RING-Tx3
WHITE 128 TIP-Tx4
GREY 113 RING-Tx4
WHITE 129 TIP-Tx5
BROWN 112 RING-Tx5
WHITE 130 TIP-Tx6
GREEN 111 RING-Tx6
WHITE 131 TIP-Tx7
ORANGE 110 RING-Tx7
WHITE 132 TIP-Tx8
BLUE 109 RING-Tx8
RED
BROWN
133 TIP-Tx9
GREEN 108 RING-Tx9
RED 134 TIP-Tx10
ORANGE 107 RING-Tx10
RED 135 TIP-Tx11
BLUE 106 RING-Tx11
WHITE 136 TIP-Tx12
GRAY 105 RING-Tx12
WHITE 137 TIP-Tx13
BROWN 104 RING-Tx13
WHITE 138 TIP-Tx14
GREEN 103 RING-Tx14
WHITE 139 TIP-Tx15
ORANGE 102 RING-Tx15
WHITE 140 TIP-Tx16
BLUE 101 RING-Tx16
