Procedure 5-14
Connecting and routing 12xE3DS3 WP cables through
IO12xE3DS3 card
Use this procedure to connect the E3/DS3 cables from the E3/DS3 interfaces
on the 12xE3DS3WP tributary circuit pack through the IO12xE3DS3 of the
6200 network element.
Prerequisites
Make sure that the following tools and materials are available:
• 12 SMB cables. For details on ordering information for the E3/DS3 cables,
refer to the Planning Guide, S78-1002-110.
• cable ties
Action
Step Action
1 Identify the SMB cables.
2 Connect the appropriate SMB cables to the IO12xE3DS3 circuit pack in the
I/O panel.
3 Connect the appropriate SMB cables to the transmit and receive ports on the
12xE3DS3WP circuit pack as shown in Figure 5-25 on page 5-45.
—end—
CAUTION
Risk of equipment damage
Electrostatic discharge can damage electrostatic sensitive
devices. Use antistatic protection to avoid damaging the shelf
and circuit packs.
