8-16 Network reconfiguration
6200 Packet-Optical Platform Installation, Commissioning, and Testing Procedures
Release 1.1 009-6200-201 Draft Issue 1
Copyright
©
2014 Ciena
®
Corporation September 2014
Procedure 8-5 (continued)
Deleting an 6200 network element from a STM-1/OC-3 ring Configuration with 15G MRO XC circuit
pack
Step Action
3 Check for the pass through cross-connects with the neighboring network
elements B and D.
Note: Traffic on all the unprotected circuits passing through either D-1-4-3 or
B-1-2-3 will be lost while deleting the network element C.
4 Force all protected cross-connections on D-1-4-3 towards D-1-2-3 (using
force to working or force to protect) and B-1-2-3 towards B-1-4-3 (using force
to protect or force to working depending on whether 1-2-3 is working or
protect, respectively).
5 At network element C, disconnect all the fibers going to network elements B
and D. Perform the necessary pass through at network element C. Measure
the Rx power at network element B and D and verify that they are within
specifications.
Refer to the Planning Guide, S78-1002-110 for the specifications.
6 If applicable, clear the forced switches, operated at step 4, on network
elements B and D.
7 Verify error free traffic to other nodes.
Refer to Provisioning and Protection Switching Procedures, 009-6200-310 for
provisioning details.
—end—
If the pass through
cross-connects are
Then go to
present step 4
not present step 5
