Installing the 6200 network element 5-41
6200 Packet-Optical Platform Installation, Commissioning, and Testing Procedures
Release 1.1 009-6200-201 Draft Issue 1
Copyright
©
2014 Ciena
®
Corporation September 2014
Procedure 5-12
Connecting and routing 63xE1DS1WP cables through
IO63xE1DS1 card
Use this procedure to connect E1DS1 WP cables through IO63xE1DS1 for
120-ohm E1 and 100-ohm DS1 applications.
Note: While inserting the E1DS1WP circuit pack, push the circuit pack all
the way in and push the latches down.
Prerequisites
Make sure that the following tools and materials are available:
• standard installer tool kit
•flat screwdriver
• E1/DS1 cables. Refer to Planning Guide, S78-1002-110
for orderable
codes
• cable ties
Action
Step Action
1 Identify the required E1/DS1 WP cable. Refer to Table 11-9 on page 11-6.
2 Connect the E1/DS1 WP cable(s) from 160 pin LFH connector(s) to 160 pin
LFH connector(s) on the IO63xE1DS1 tributary circuit pack. as shown in
Figure 5-23 on page 5-42.
3 The procedure is complete.
Note: When connecting the E1 ports 33-63 of the IO63xE1DS1 circuit pack
to the termination panel, the additional overlay label delivered with the
termination panel can be installed for proper port number identification prior
to connecting the E1 traffic cables.
—end—
