Ciena 6200 - Connecting the 6200 to Local Safety Ground

5-8 Installing the 6200 network element
6200 Packet-Optical Platform Installation, Commissioning, and Testing Procedures
Release 1.1 009-6200-201 Draft Issue 1
Copyright
©
2014 Ciena
®
Corporation September 2014
Procedure 5-2
Connecting the 6200 to local safety ground
Use this procedure to connect the 6200 network element to local safety
ground.
Note: To perform this procedure, you must ensure that the equipment
rack is correctly grounded according to local grounding practices. The
safety ground connection must always be made first and disconnected last
while installing or replacing the unit.
Prerequisites
Make sure that the following tools and materials are available:
• standard installer tool kit
• one number of grounding cable for the base chassis, and another number
of grounding cable for the expansion chassis if you have purchased the
expansion chassis.
• Manual Phillips screwdriver (PH3, PH1)
Action
Step Action
1 Remove the Phillips screw from the 6200.
2 Fasten the grounding cables to the local safety points on the 6200 base and
expansion chassis as shown in the Figure 5-3 on page 5-10.
Note: There are separate local safety ground points at the rear of the 6200
base/main and expansion chassis.
3 Route the grounding cable securely along the rack and terminate it according
to local site practices.
CAUTION
Risk of equipment damage
Electrostatic discharge can damage electrostatic sensitive
devices. Use antistatic protection to avoid damaging the shelf
and circuit packs.
CAUTION
Risk of improper ground due to poor contact with a painted rack
If the rack is painted, follow your company’s procedures to
remove the paint from the area where the bolt will be fastened.
Ensure the bolt washer makes direct contact with the rack.
