Installing the 6200 network element 5-5
6200 Packet-Optical Platform Installation, Commissioning, and Testing Procedures
Release 1.1 009-6200-201 Draft Issue 1
Copyright
©
2014 Ciena
®
Corporation September 2014
Procedure 5-1
Installing the 6200 shelf
Use this procedure to install the 6200 network element in a 19 in./ 21 in./ 23
in. rack.
Prerequisites
Make sure that the following tools and materials are available:
• standard installer tool kit
• Manual Phillips screwdriver (PH3) and (PH1)
• eight M6 mounting screws and captive nuts for the combined (base/main+
expansion) chassis or four M6 mounting screws and captive nuts for only
the base/main chassis.
Action
Step Action
Rack mounting
1 Determine your next step.
2 Remove the standard 19 in. rack mounting bracket from the 6200 and fit the
corresponding mounting bracket available in the accessories kit. Refer to
Figure 5-2 on page 5-7 Figure 5-2 for the accessories provided in the
accessories kit.
3 Determine the front mounting position.
4 Determine the access requirements and select the side you want to use as
the front side in the rack.
If you want to install the 6200 in Then go to
a 19 in. rack step 3
a
21 in. or 23 in. rack step 2
If you want to front mount Then
the flange in face with the 6200 go to step 4.
See Figure 5-1 on page 5-6.
130 mm away from the front face of
the 6200 to fix the cable router
fasten the flange and the cable
routing brackets 130 mm away from
the face of the 6200, See Figure 5-1
on page 5-6.
