Procedure 5-5
Connecting the LAN and Craft cables
Use this procedure to connect the Craft cable to the Craft or LAN cable to the
LAN ports of the 6200 network element.
The network LAN and Craft cable interface is RJ-45 type and this interface is
used for network connectivity. The Ethernet cables that connect to the LAN
and Craft ports of the Fan+OAM or Fan+OAMV2 circuit pack must be Shielded
Twisted Pair (STP) type. For details on ordering information for the Ethernet
cables, refer to the Planning Guide, S78-1002-110.
Prerequisites
Make sure that you have the LAN and Craft cable.
Action
Step Action
1 Connect the Craft cable to the corresponding Craft port or LAN cable to the
corresponding LAN port on the Fan+OAM or Fan+OAMV2 circuit pack as
shown in Figure 5-8 on page 5-19, Figure 5-9 on page 5-20, Figure 5-10 on
page 5-21, and Figure 5-11 on page 5-22.
2 Ensure that the retention slides operate to hold the connectors in place.
3 Route the cables and route them securely along the left side of the rack.
For LAN/Craft cable color coding details, see Table 11-8 on page 11-5.
—end—
