Preparing for installation and commissioning 4-3

6200 Packet-Optical Platform Installation, Commissioning, and Testing Procedures

Release 1.1 009-6200-201 Draft Issue 1

2014 Ciena

Corporation September 2014

Power requirements

The 6200 supports two 325 W DC or two 500W DC or two 290W AC power

supplies for the base chassis and two 250 W DC power supplies for the

expansion chassis

The power supply module provides the following functionality:

• Operating voltage range is -40 V to -72 V for DC PSU and 265 V to 90 V

for APU290

• minimum input current requirement per base PSU is 8.5A (325W PSU),

14.5A (500W PSU), 3.5A (APU290), and per expansion PSU is 6.5A

(250W PSU)

• input low voltage indication (with accuracy of +/- 6%) to the user interface

for low voltage alarms

• input high voltage indication (with accuracy of +/- 6%) to the user interface

for high voltage alarms

Note: Ensure that in redundant state, the two slots allotted to power

supply modules on base chassis or expansion chassis are occupied by

same PSU type.

5/7-slot PSU Filler 0.3 kg

7-slot AC PSU Filler 0.3 kg

5-slot expansion I/O Filler Card 0.4 kg

5-slot expansion Air Filter with Tray 0.7 kg

Table 4-1 (continued)

6200 physical dimensions

Specification Description
