4-2 Preparing for installation and commissioning
6200 Packet-Optical Platform Installation, Commissioning, and Testing Procedures
Release 1.1 009-6200-201 Draft Issue 1
Copyright
©
2014 Ciena
®
Corporation September 2014
Expansion chassis width (including mounting
flanges)
482 mm
Basic chassis width (excluding mounting flanges) 444 mm
Expansion chassis width (excluding mounting
flanges)
444 mm
7-slot 325W DC PSU 0.6 kg
7-slot 500W DC PSU 0.3 kg
7-slot 290W AC PSU 0.66 kg
5-slot Expansion 250W DC PSU 0.4 kg
15G MRO XC Card 0.6 kg
60G MRO XC Card 0.6 kg
6G PKT SW Card 0.65 kg
64G PKT SW Card 0.6 kg
63xE1DS1 Card 0.4 kg
63xE1DS1 WP Card 0.4 kg
IO63xE1DS1 Card 0.5 kg
6xE3DS3 Card 0.4 kg
12xE3DS3WP Card 0.31 kg
IO12xE3DS3 Card 0.56 kg
2.5G MRO Card 0.32 kg
4xGE + 4xFE Card 0.5 kg
7-slot base Fan Tray and OAM 0.63 kg
7-slot base Fan Tray and OAMV2 0.74 kg
7-slot base Air Filter with Tray 0.6 kg
7-slot base chassis with Air Filter and Tray 6 kg
5-slot expansion chassis with Air Filter and Tray 7 kg
5-slot expansion Fan Tray 1 kg
5/7-slot XCC/Trib Filler 0.4 kg
Table 4-1 (continued)
6200 physical dimensions
Specification Description
