Ciena 6200 - Page 237

Cable color coding 11-7
6200 Packet-Optical Platform Installation, Commissioning, and Testing Procedures
Release 1.1 009-6200-201 Draft Issue 1
Copyright
©
2014 Ciena
®
Corporation September 2014
Tx GROUP
RED
YELLOW
141 TIP-Tx17
GREEN 100 RING-Tx17
RED 142 TIP-Tx18
ORANGE 99 RING-Tx18
RED 143 TIP-Tx19
BLUE 98 RING-Tx19
WHITE 144 TIP-Tx20
GRAY 97 RING-Tx20
WHITE 145 TIP-Tx21
BROWN 96 RING-Tx21
WHITE 146 TIP-Tx22
GREEN 95 RING-Tx22
WHITE 147 TIP-Tx23
ORANGE 94 RING-Tx23
WHITE 148 TIP-Tx24
BLUE 93 RING-Tx24
RED
WHITE
149 TIP-Tx25
GREEN 92 RING-Tx25
RED 150 TIP-Tx26
ORANGE 91 RING-Tx26
RED 151 TIP-Tx27
BLUE 90 RING-Tx27
WHITE 152 TIP-Tx28
GRAY 89 RING-Tx28
WHITE 153 TIP-Tx29
BROWN 88 RING-Tx29
WHITE 154 TIP-Tx30
GREEN 87 RING-Tx30
WHITE 155 TIP-Tx31
ORANGE 86 RING-Tx31
WHITE 156 TIP-Tx32
BLUE 85 RING-Tx32
Table 11-9 (continued)
E1/DS1 LFH Cable
Group Cable Pins on the
Connector
Signal
Pair Color Bundle Color
